Produkt-Code
hhi8
Technische Informationen
Hauptmerkmale
Dicke:
10 mm
V1
Merkmale
ISO 10545-2
Length and width Suitable for
Dicke Suitable for
Straightness of sides Suitable for
Perpendicularity Suitable for
ISO 10545-2
Surface Flatness Suitable for
ISO 10545-3
Water Absorption (in % by mass) 10%<EV<=20%
ISO 10545-4
Breaking strenght S >=600 N
Bending resistance R >=15 N/mm2
10545-8
Coefficient of thermal linear expansion <=7MK-1
10545-9
Thermal shock resistance Resistant
10545-10
Moisture expansion (in mm/m) <=0.06% (0.6mm/m)
Bond strength/adhesion for improved cementitious adhesives
Bond strength/adhesion for improved cementitious adhesives >=1.0 N/mm2 (Class C2 - EN 12004)
Reaction to fire A1
ISO 10545-13
Resistance to household chemicals and swimming pool salts A
Resistance to low concentration of acids and alkalis LA
Resistance to high concentrations of acids and alkalis HA
ISO 10545-14
Stain resistance 5
