Informations techniques
Caractéristiques principales
Épaisseur:
9 mm
V3
Certifications
Caractéristiques
ISO 10545-2
Length and width Suitable for
Épaisseur Suitable for
Straightness of sides Suitable for
Perpendicularity Suitable for
ISO 10545-2
Surface Flatness Suitable for
ISO 10545-3
Water Absorption (in % by mass) <=0.1%
ASTM C373-18
Water Absorption (in % by mass) <=0.5%
ISO 10545-4
Breaking strenght S >=1000 N
Bending resistance R >=40 N/mm2
ISO 10545-5
Impact resistance, as coefficient of restitution >=0.55
ISO 10545-6
Resistance to deep abrasion of unglazed tiles (removed volume) <=150mm3
10545-8
Coefficient of thermal linear expansion <=7MK-1
10545-9
Thermal shock resistance Resistant
10545-10
Moisture expansion (in mm/m) <=0.01% (0.1mm/m)
10545-12
Frost resistance Resistant
Bond strength/adhesion for improved cementitious adhesives
Bond strength/adhesion for improved cementitious adhesives >=1.0 N/mm2 (Class C2 - EN 12004)
Reaction to fire A1 - A1fl
ISO 10545-13
Resistance to household chemicals and swimming pool salts A
Resistance to low concentration of acids and alkalis LA
Resistance to high concentrations of acids and alkalis 0
ISO 10545-14
Stain resistance >= 3
DIN EN 16165 ANNEX B (EX DIN 51130)
Booted ramp test N.C.
BS EN 16165 ANNEX C (EX BS 7976)
Pendulum friction Test >= 36 Dry <= 24 Wet
B.C.R.A. Rep. CEC/81
Coefficient of friction (COF) >0.40Asciutto <0.40Bagnato
ANSI A 326,3
Dynamic coefficient of friction (DCOF) Dry DCOF >= 0.42
